Delay On Make Relays (DOM) : Time Delay Relays

Switch Selectable Time Delay

When power is applied to the input, the time delay begins. After the time delay is complete, the load energizes.

DETAILS:

• Highly precise digital timing
• Switch-settable time delays
• Ideal for ice machine applications
• Universal voltage operation
• Repeat accuracy .5% over voltage and temperature range

SPECIFICATIONS:

INPUT

Voltage: 18-240 VAC 1 amp 10 amp in-rush 40mA holding current Switch-Settable Time Delay: From 1-1,023 seconds

Delay On Make Relays : Time Delay Relays

When power is applied to the input, the time delay begins. After the time delay is complete, the load energizes and remains energized as long as power is applied. The control is reset by removing power during or after the time delay period.

Knob Adjustable Time Delay: 10-1,000 seconds Very limited stock of ICM104B : 240V

3-Phase Monitor

Protect your most valuable investments!

The ICM401A offers affordable protection against phase loss / reversal and unbalance. Upon application of power with the safety switches closed, the load will energize. If any of the safety switches open for longer than 600 ms, the fault light will come on and the load will stay de-energized regardless of the state of the safety switches. Power must then be removed for 100 ms and safety switches must be closed in order to re-energize the load, upon which the fault light will be off.

Details:

The ICM401A offers affordable protection against phase loss / reversal and unbalance.

• Low-cost 3-phase protection for single side
• Monitors for phase reversal, phase loss, and unbalance % as a function of input voltage
• Bright LED indicators for ON and FAULT
• Universal 3-phase input: 180-600 VAC
• Control voltage: 18-32 VAC
• Epoxy-encapsulated for moisture protection
