Petross P6865HG-M & P6865HG-R Thermostats
Key Shared Features (P6865 Series):
- Voltage: 24VAC.
- Application: 2-pipe/4-pipe fan coil control.
- Fan Control: Manual or automatic 3-speed.
- Temperature Range: 10 C to 32 C
- Display: Large LCD with English/Icons.
- Features: Time on/off, remote sensor option, energy-saving mode (dry contactfor key card).
| Brand |
|---|
The PETROSS P6865HG-M and P6865HG-R are horizontal thermostat models within the P6865 series, which are designed for 3-speed fan coil units with 24VAC power supply. Both feature a horizontal, large green LCD display with a white housing.
P6865HG-R (Modulating): This model is designed for 3-speed fan and modulating valves (0-10V or similar) in fan coil systems. Allows remote sensor function. Replaces T6865H2WG-R
P6865HG-M (Motorized/On-Off): Typically denotes suitability for motorized, on/off valve control rather than proportional modulating control. Built-in sensor. Replaces T6865H2WG-M
Summary Recommendation:
Choose the P6865HG-R if you have a modulating actuator (e.g., 0-10V).
Choose the P6865HG-M if you have a standard on/off valve actuator.
