INFICON D-TEK Stratus Refrigerant Leak Detector with Parts Per Million (PPM) Display
INFICON D-TEK STRATUS® REFRIGERANT LEAK DETECTOR AND PORTABLE MONITOR
Find Profit-Crushing Leaks in No Time
D-TEK Stratus combines the superior leak detection of INFICON D-TEK leak detectors with the cloud hunting capability of a portable monitor all in one hand-held unit.
Quickly locate the area containing the leak using the large, easy-to-read LCD display, and then pinpoint the leak all with one instrument! D-TEK Stratus is the next big thing in refrigerant leak detection.
FEATURES
- Automatic and manual zero modes
- Rugged carrying case included
- Detects all CFCs, HCFCs, HFCs, and HFOs
TYPICAL APPLICATIONS
- Industrial AC & Refrigeration
Advantages of D-TEK Stratus
Innovative Cloud Hunting® mode with ppm readout helps locate leaks faster than ever
Cloud Hunting and pinpoint modes is like having two leak detectors in one
All new, redesigned infrared sensor
Longest sensor life in the industry
Easy field replacement
New lithium ion battery
Quick charge capability
Easy field replacement
Designed for
|
Specifications |
|
|---|---|
|
Includes |
D-TEK Stratus Infrared sensor Lithium ion battery Spare filters AC wall charger DC car charger Extra-long probe Carrying case Earbuds |
| Refrigerant sensor | R22, R32, R134a, R404a, R407c, R410a, R422b, R448a, R449a, R452a, R452b, R507 (AZ50), R1234yf, ammonia, SF6, HFE and more |
|
CO2 Sensor |
R744 (CO2) |
| Flammable Refrigerant Sensor |
R290, R600a, R441a |
| Sensitivity per EN14624 |
R744 (CO2) - 2 g/a (0.07 oz./yr)1 R1234yf - 0.5 g/a (0.02 oz./yr)
Ammonia - 3 g/a (0.1 oz./yr)
R290 - 5 g/a (0.2 oz./yr)2
R134a - 1 g/a (0.04 oz./yr) |
| Power Source |
Lithium ion battery (rechargeable)
Micro USB (can operate while charging) |
| Certifications |
EN14624:2020 A2L Certified |
|
1 Requires 724-701-G2 CO2 Sensor 2 Requires 724-701-G3 Flammable Refrigerant Sensor |
|
Related products
WIPCOOL C10BW Integrated Coil Cleaning Machine
Main features
- Provides excellent mobility, equipped with wheels and a push handle.
- Two power options are available: AC-powered or 18V Li-ion powered.
- Integrated solution with an 18L clean water tank and a 2L chemical tank.
- Offers excellent mobility and includes a back strap for ultimate portability.
The integrated coil cleaning machine C10Bw is ideal for cleaning in locations where water and power may be inaccessible. It can be powered by AC or an 18V lithium battery and offers 6 optional battery adapters. You can use your own batteries if they are compatible with any of these adapters.
In addition, this machine provides a fully integrated coil cleaning solution with an 18L clean water tank and a 2L chemical tank. The trolley case design offers excellent mobility, and an optional back strap allows you to carry the cleaning machine hands-free, making it easy to climb ladders to specific job sites, such as attics or roofs. This versatility makes it suitable for almost any coil cleaning application.
Unlike traditional high-pressure cleaning machines and low-pressure sprayers, this machine is specially designed for HVAC coils, providing two adjustable cleaning pressures. You can select between 5 bar and 10 bar depending on the cleaning requirements, ensuring the cleanest coils you've ever had.
| Model | C10BW |
| Voltage | 18V (AEG/ RIDGID interface) |
| Pressure | 3-5 /7-10 bar (Dual) |
| Flow Rate(Max.) | 4L/min |
| Reference Running Time | 50-120mins (4.0AhLi-ion battery) |
| Reference Charging Time | 210 mins.(4.0AhLi-ion battery) |
| Motor Power | 80W |
| Tank Capacity | 18L clean water tank +2L chemical tank |
| Outlet Hose | 5m |
| Weight (Dry) | 6.6kg (w/o battery) |
