• Slimmest body design, flexible installation.
• Built-in safety switch, avoid the overflow when drainage failure
• Unique motor balance technology, reduce vibration.

Product Features

The P12 condensate pump adopts a slim body design and is WIPCOOL's slimmest mini pump. Specially designed for narrow spaces, it is mainly installed in the back interior of split air conditioners. It can also be applied in ducted air conditioners and cassette air conditioners. It is suitable for devices with a cooling capacity under 30,000 BTU/hr.

With a built-in safety switch and unique motor balance technology, the pump operates silently for extended periods and guarantees safe drainage.

Model	P12
Voltage	100V-230V~/ 50-60Hz
Suction Lift(Max.)	2m (6.5ft)
Discharge Head(Max.)	7m (23ft)
Flow Rate(Max.)	12L/h (3.2GPH)
Tank Capacity	35 ml
Mini Splits up to	30,000btu/hr
Sound Level at 1m	19dB(A)
Ambient Temp.	0ºC~50ºC

Why Choose WIPCOOL Supermarket Condensate Pump

• Compact and Powerful
• Quite and Reliable
• Innovation driven
• Easy Maintenance

Mini Pump Series

WIPCOOL offers the most complete and high-performance range of mini pumps worldwide. They are widely applied in split, ducted-type, and cassette-type air conditioning units, as well as other appliances that produce small amounts of condensate.

Some items are equipped with a brushless motor, safety switch, and probe sensor, which maintain the pump's high performance and ensure silent, durable operation with a long service life.

Mini Pump Series Selection Guide

Model	Max. unit output	Applicable A/C	Applicable place	discharge head(max.)
P20	30,000Btu/h	Split unit, Floor mounted unit.	Smaller commercial and domestic units in quite environments.	10m
P38	45,000Btu/h
P18	30,000Btu/h
P36	45,000Btu/h
P16	30,000Btu/h	Ducted units; Floor standing & Chassis units; High wall split systems
P32	45,000Btu/h
P12	30,000Btu/h			7m
P12C	30,000Btu/h

• Made of stainless steel case with 3L large reservoir
• Ideal for cold produce display cabinets in supermarkets and convenience stores.
• Low profile (69mm height) for extremely easy to install and maintenance.
• Built of heat resistant material, suitable for handling 70ºC high temperature water.

Product Features

The P120S is specially designed to handle condensate from supermarket refrigerated display cabinets. It is extremely easy to install and maintain.

The compact design of the pump facilitates installation under low-slung display cabinets and removes water during the defrost cycle.

Including an easy-to-clean stainless steel tank that can handle hot water up to 70ºC, a non-return valve, and two optional inlets (top or side). It effectively pumps away defrost water and debris.

Model	120S
Voltage	230V~/50-60Hz or 100-120V~/50-60Hz
Discharge Head(Max.)	30m(98ft )
Flow Rate(Max.)	120L/h (32GPH)
Tank Capacity	3L
Sound Level at1m	40-62dB(A)
Water Temp.	Max 75ºC
Power	30W

Why Choose WIPCOOL Supermarket Condensate Pump

• Easy Maintenance
• Time saving
• High performance
• Industry leading

Supermarket Condensate Pump Selection Guide

Supermarket Condensate Pump

WIPCOOL supermarket condensate pump features a compact design, ideal for cold produce display cabinets in supermarkets and convenience stores. It is especially suitable for handling condensate from supermarket refrigerated display cabinets.

It is extremely easy to install and maintain. The built-in high-level safety switch can either enable the system to be switched off or sound an alarm in the event of pump failure.

Model	Max. unit output	Applicable	Applicable place	discharge head(max.)
P120S	300,000Bt/h	Single and multiple refrigeration units; Cold store cabinets.	Cold Stores, Super Markets	30m
P360S	500,000Bt/h			36m

Main Features

• Buckle type fixed structure, simple installation.
• 5 inlets for optional (4 top & 1 side), easy to use.
• Low profile design, good fit for those instances where space is at a premium.

The P380 tank pump provides the most economical solution for drainage demands with a lift within 7 meters and a flow rate within 400L/h. It is suitable for devices with a cooling capacity under 500,000 BTU/hr.

Adopting a high-performance water pump with a built-in safety switch and probe level sensor ensures reliable long-term operation. Additionally, this pump is only 119mm in height, making it an excellent fit for instances where space is at a premium

Model	P380
Voltage	100V-230V~/50-60Hz
Discharge Head(Max.)	6.8m(22ft)
Flow Rate(Max.)	380L/h (100GPH)
Tank Capacity	1.8L
Sound Level at 1m	28dB(A)
Ambient Temp.	0ºC~50ºC
Power Consumption	20W

Why Choose WIPCOOL Tank Pump?

• Easy Installation
• Durable Running
• High Performance
• Industry Leading

Tank Pump Series

WIPCOOL focuses on innovation and has created a market-leading range of tank pumps, covering 5 lift levels and flow rates: [10m, 40L/h], [3.5m, 110L/h], [4.5m, 180L/h], [6.8m, 380L/h], [12m, 580L/h], designed to suit a diverse array of applications.

Easy to install and maintain, with features including an easy-clean tank, plug-and-play functionality, a twist-and-click non-return valve, and a built-in spirit level. With reliability as the key decision criterion, the tank pumps are designed to perform even under the most challenging applications.

Tank Pump Series Selection Guide

Model	Max. unit output	Applicable A/C	Applicable place	discharge head(max.)
P40	45,000Bt/h	Split unit; Cassette unit; Ducted unit; Floor mounted unit	Commercial and domestic units in quiet environments	10m
P110	150,000Bt/h			3.5m
P180	400,000Bt/h	Floor mounted unit; Dehumidifiers; Ice makers; Air handling units(AHUs)	Large commercial units	5m@50Hz 6m@60Hz
P380	500,000Bt/h			6.8m
P580	500,000Bt/h			12m

Main Features

• Super performance(12m lift head, 580L/h flow rate)
• Forced air cooling brushless motor, ensure stable running.
• Anti-backflow design, guarantee the safety drainage
• Dual sensor control system, improve durability.

The P580 tank pump provides the most economical solution for extreme drainage conditions, with a lift height of 12 meters and a flow rate of 600L/h. It is suitable for devices with a cooling capacity under 500,000 BTU/hr.

Adopting a brushless motor, dirt-resistant high-power centrifugal water pump, built-in safety switch, and dual control level sensor (probe and float) ensures that the product can operate reliably for a long time and safely discharge condensate.

Model	P580
Voltage	230V~/50-60Hz or 100-120V~/50-60Hz
Discharge Head(Max.)	12m(40ft)
Flow Rate(Max.)	580L/h (153GPH)
Tank Capacity	1.8L
Sound Level at 1m	60dB(A)
Ambient Temp.	0ºC~50ºC
Power Consumption	85W

Why Choose WIPCOOL Tank Pump?

• Easy Installation
• Durable Running
• High Performance
• Industry Leading

Tank Pump Series

WIPCOOL focuses on innovation and has created a market-leading range of tank pumps, covering 5 lift levels and flow rates: [10m, 40L/h], [3.5m, 110L/h], [4.5m, 180L/h], [6.8m, 380L/h], [12m, 580L/h], designed to suit a diverse array of applications.

Easy to install and maintain, with features including an easy-clean tank, plug-and-play functionality, a twist-and-click non-return valve, and a built-in spirit level. With reliability as the key decision criterion, the tank pumps are designed to perform even under the most challenging applications.

Tank Pump Series Selection Guide

Model	Max. unit output	Applicable A/C	Applicable place	discharge head(max.)
P40	45,000Bt/h	Split unit; Cassette unit; Ducted unit; Floor mounted unit	Commercial and domestic units in quiet environments	10m
P110	150,000Bt/h			3.5m
P180	400,000Bt/h	Floor mounted unit; Dehumidifiers; Ice makers; Air handling units(AHUs)	Large commercial units	5m@50Hz 6m@60Hz
P380	500,000Bt/h			6.8m
P580	500,000Bt/h			12m
