Wipcool PCW-4W Pressure Washers
Portable Coil Cleaning Machine With Water Tank
- Integrated Design with nozzle, hose and accessories
- Allows the HVAC technician to be mobile
- Allows cleaning in areas where water is not easily available like deserts or rooftops.
- 16L clean water tank allows the HVAC technician to be free from water mains
- Includes adjustable shoulder strap for easy mobility
- Specialized and balanced pressure (5bar / 10 bar) that’s safe on the air conditioner’s coils Voltage – 230V 50Hz Flow Rate – 4L / min Water Tank – 16L
WIPCOOL PT-25 Floating Ball Condensate Trap
Features
- Smooth drainage, Enjoy fresh air
- Anti- back flow & blockage, prevent smelly&insect-resistant
- Controlled by floating ball valve,Suitable for all seasons
- No need to inject water when it is dry
- Buckle design, easy to maintain and clean
Product description
The WIPCOOL floating-ball condensate trap is designed to solve the problems of outdoor air reflux, odor, and harmful insect invasion in the condensate discharge pipeline of the air conditioning.
By floating the ball up and down, the disadvantage of traditional water traps not being able to perform their water sealing function during dry seasons is avoided. Adopting a buckle design, it is easy to install, easy to maintain, and provides users with a fresh indoor environment.
| Model | PT-25 |
|---|---|
| Inner diameter | Ø25 |
| Outer diameter | Ø32 |
| Negative Pressure | 1200Pa |
| Gross weight | 115g |
WIPCOOL S1.5 Vacuum Pump S Series 4 CFM
The S Series of single stage vacuum pumps are a great range when price is a major consideration that are available in a wide range of capacities and flow rates..
The S Series of vacuum pumps are available from 2-4 CFM (57-113 LPM). They are ideal for split systems,light duties in automotive and small commercial applications.
Features a full clear oil reservoir to give you an instant indicator of the condition of your oil and system. Customized specially engineered plastic ABS is used for durable usage, troubleshooting problems quickly and to easily repair or replace the parts.
| Model |
S1 |
S1.5 |
S2 |
|
| Voltage |
230V~/50-60Hz or 100-120V~/50-60Hz |
|||
|
Stages |
1 Stage Vacuum Pumps | |||
| Ultimate Vacuum | 150 microns | |||
| Input Power | 1/4HP | 1/4HP | 1/3HP | |
| Flow Rate (Max.) | 2CFM, 57L/min | 3CFM, 85 L/min | 4CFM, 113 L/min | |
| Oil Capacity | 230ml | 210ml | 200ml | |
|
Weight |
3.3kg | 3.4kg | 3.6kg | |
|
Dimension |
266 x 121 x 194 mm |
|||
|
Inlet Port |
1/4" SAE | |||
Wipcool S series vacuum pump
WIPCOOL S2 Vacuum Pump S Series 6 CFM
The S Series of single stage vacuum pumps are a great range when price is a major consideration that are available in a wide range of capacities and flow rates..
The S Series of vacuum pumps are available from 2-4 CFM (57-113 LPM). They are ideal for split systems,light duties in automotive and small commercial applications.
Features a full clear oil reservoir to give you an instant indicator of the condition of your oil and system. Customized specially engineered plastic ABS is used for durable usage, troubleshooting problems quickly and to easily repair or replace the parts.
| Model |
S1 |
S1.5 |
S2 |
|
| Voltage |
230V~/50-60Hz or 100-120V~/50-60Hz |
|||
|
Stages |
1 Stage Vacuum Pumps | |||
| Ultimate Vacuum | 150 microns | |||
| Input Power | 1/4HP | 1/4HP | 1/3HP | |
| Flow Rate (Max.) | 2CFM, 57L/min | 3CFM, 85 L/min | 4CFM, 113 L/min | |
| Oil Capacity | 230ml | 210ml | 200ml | |
|
Weight |
3.3kg | 3.4kg | 3.6kg | |
|
Dimension |
266 x 121 x 194 mm |
|||
|
Inlet Port |
1/4" SAE | |||
Wipcool S series vacuum pump
